| Power supply |
230+/-10%-1-50 |
V-ph-Hz |
| Cooling |
Power supply |
230+/-10%-1-50 |
| Nominal Capacity (Tr) |
1.5 Tr |
| Capacity – Full |
5276 Watts |
| Capacity – Half |
2638 Watts |
| Power Consumption – Full |
1850 Watts |
| Current Full Load |
8.1 Ampere |
| Indoor coil |
Number of rows |
3 |
| Fin type (code) |
Hydrophilic aluminium |
| Tube outside dia.and type |
Φ7, inner groove tube mm |
| Indoor air flow (Hi/Med/Lo) |
|
925/740/652 m3/h |
| ESP |
Rated |
10pa |
| Sound level (sound pressure) |
|
40/34/33 dB(A) |
| Indoor unit |
NET Dimension(WxDxH) |
822x605x210 mm |
| Gross Packing (WxDxH) |
1010x680x290 mm |
| Net/Gross weight |
22.5 / 28.5 Kg. |
| Drainage water pipe dia. |
|
ODΦ27.5mm |
| Refrigerant piping |
Liquid side/ Gas side |
Φ6.35/Φ12.7( 1/4″ /1/2″ mm |
| Controller |
|
Wired control |
| Operation temperature |
Cooling |
17~32 |
